Prefabricated apartment buildings are a modern construction solution that utilizes prefabricated components and modular design. Through factory production and on-site rapid assembly, they offer efficient, eco-friendly, and intelligent living spaces.
Product Description
Prefabricated apartment buildings are a modern construction solution that utilizes prefabricated components and modular design. Through factory production and on-site rapid assembly, they offer efficient, eco-friendly, and intelligent living spaces. Suitable for urban housing, rental apartments, student dormitories, and more, they meet the modern demand for high-quality, fast-delivery, and sustainable living solutions
Product Information
Structural System: Uses cold-formed thin-walled steel as the framework, combined with lightweight composite panels, to create a durable and robust building structure.
Integrated Functions: Combines load-bearing, insulation, fire resistance, soundproofing, and moisture-proofing features to enhance living comfort.
Smart Design: Supports integration with smart home systems, enabling remote control and energy management for modern, intelligent living.
Fast Delivery: From design to completion, the construction period is only 1/3 of traditional methods, significantly reducing project timelines.
|
Category |
Type |
Specifications |
Features/Applications |
|
Steel Sections |
H-Beam |
H100×100 to H400×400 (height × width, unit: mm) |
Reasonable cross-section, strong load-bearing, suitable for main beams, columns, etc. |
|
|
I-Beam |
I10 to I63 (height, unit: cm) |
Suitable for secondary beams, supports, etc. |
|
|
Angle Steel |
L30×30×3 to L100×100×10 (side length × side length × thickness, unit: mm) |
Used for supports, connectors, etc. |
|
|
Channel Steel |
[10 to [40 (height, unit: cm) |
Suitable for secondary beams, supports, etc. |
|
Steel Plates |
Thickness |
6mm to 50mm |
- 6mm to 12mm: Lightweight structures or non-primary load-bearing parts. |
|
|
|
|
- 12mm to 25mm: Medium-load structures. |
|
|
|
|
- Above 25mm: Heavy-load structures. |
|
|
Width & Length |
Customized, common width: 1.5m to 3m, length: 6m to 12m |
Designed based on specific requirements. |
|
Steel Pipes |
Round Pipe |
Φ50×3 to Φ300×12 (outer diameter × wall thickness, unit: mm) |
Used for columns, supports, etc. |
|
|
Square Pipe |
□50×50×3 to □200×200×10 (side length × side length × wall thickness, unit: mm) |
Used for frame structures, supports, etc. |
|
Connectors |
Bolts |
M12 to M24 (diameter, unit: mm), strength grades: 8.8, 10.9 (high-strength bolts) |
High-strength fasteners for secure connections. |
|
|
Welding Materials |
Electrodes: E43 series (for Q235 steel), E50 series (for Q345 steel) |
Selected based on steel type for welding applications. |
|
|
Welding Wire |
Customized based on steel type |
Ensures strong and durable welds. |
|
Wall Panels |
Core Material |
Modified cement perlite composite core |
Lightweight, high strength, excellent thermal insulation and fire resistance. |
|
|
Surface Layer |
Glass fiber mesh with polymer crack-resistant mortar |
Enhances durability and weather resistance. |
|
Roof Panels |
Material |
Lightweight waterproof panels |
High wind pressure resistance, excellent weather resistance. |
Key Advantages
Efficient Construction: Prefabricated components are factory-produced, enabling rapid on-site assembly and reducing construction time by 25%-30%.
Eco-Friendly: Reduces construction waste by 70%, saves 25% water usage, and lowers energy consumption by 20%.
Seismic Performance: Combines steel structure with lightweight core materials, offering excellent earthquake resistance.
Flexible Design: Modular design supports customizable layouts, adapting to various terrains and project requirements.
Cost-Effective: Reduces labor and material waste, lowering overall costs by 15%-20%.
Applications
Urban Housing: Meets the demands of rapid urbanization, providing high-quality living spaces.
Rental Apartments: Ideal for long-term rental apartments and youth apartments, offering quick delivery and high ROI.
Student Dormitories: Modular design is suitable for large-scale dormitory construction, with short timelines and cost efficiency.
Temporary Housing: Suitable for post-disaster reconstruction and emergency housing needs.
Target Audience
Real Estate Developers: Seeking efficient, cost-effective, and eco-friendly construction solutions.
Government Agencies: For public projects such as affordable housing and disaster recovery.
Educational Institutions: Building student dormitories and faculty housing.
Rental Operators: Rapidly constructing long-term rental apartments to meet market demand.
Shipping, Packaging, and Transportation
Packaging: Uses moisture-proof and shock-resistant packaging to ensure components remain undamaged during transit.
Transportation: Depending on project scale, components are shipped via containers or flatbed trucks, with nationwide delivery support.
Delivery Time: Typically 15-30 days from order to shipment, depending on project size.
FAQ
Q: What is the lifespan of prefabricated apartment buildings?
A: The design lifespan is over 50 years, and regular maintenance can extend this further.
Q: Is customized design supported?
A: Yes, fully customizable designs are available to meet specific layout and functional requirements.
Q: Does the construction process generate a lot of waste?
A: Compared to traditional construction, waste is reduced by 70%, making it more eco-friendly.
Q: How is the seismic performance of prefabricated apartment buildings?
A: The combination of steel structure and lightweight core materials provides excellent earthquake resistance, capable of withstanding magnitude 8 earthquakes.
Q: Can the buildings be modified after delivery?
A: The modular design allows for flexible post-construction modifications to meet changing needs.
